A programmable benchtop temperature chamber, also called a benchtop thermal chamber, or benchtop temperature chamber, is designed to simulate full ranges of temperature conditions, and the small footprint makes it optimal for testing small components and products on a benchtop in a laboratory. Programmable benchtop temperature chamber provides accurate temperature control with PID function. Customers can perform temperature tests with a range of -40°C~+130°C.
Model: TGDW-12
Capacity: 12L
Shelf: 1pc
Color: Off-white
Interior dimension: 310×230×200 mm
Exterior dimension: 500×540×650 mm
Description
Climatest Symor® programmable benchtop temperature chamber can control and maintain precise temperature conditions within a small, enclosed space. These chambers are widely used in research and development, quality control, and various industrial applications to simulate specific environmental conditions.
Specification
| Model | TGDW-12 | TGDW-22 | TGDW-36 |
| Interior Dimension(W*D*H) | 310×230×200 mm | 320×250×250 mm | 400×300×300 mm |
| Exterior Dimension(W*D*H) |
500×540×650 mm |
520×560×730 mm |
640×730×970 mm |
| Temperature Range | Model A :-20°C~+130°C Model B: -40°C~+130°C | ||
| Temperature Fluctuation | ≤±0.5°C | ||
| Temperature Bias | ≤±1.0°C | ||
| Temperature Uniformity | ≤1.5°C | ||
| Heating Rate | +25℃～+130℃≤30 minutes (unload) | ||
| Cooling Rate | +25℃～-40℃≤45 minutes (unload) | ||
| Interior Material | SUS#304 brushed stainless steel | ||
| Exterior Material | Reinforced Steel plate with electrostatic spraying | ||
| Insulation | Superfine fiberglass wool/polyurethane foam | ||
| Controller | 7” Programmable touchscreen controller | ||
| Circulation System | Low-noise, high-temperature resistant motors, long axis and stainless steel multi-leaf type centrifuge fan | ||
| Heating System | NiCr heater, independent system | ||
| Refrigeration System | France "TECUMSEH" Refrigeration Compressors, air cooling | ||
| Power Supply | AC110V/220V/AC230V·50HZ/60HZ | ||
Safety protection:
· Independent temperature limiter
· Over-heat, over-current and over-pressure protection of compressor.
· Over-temperature protection, overheat of fan and motor, phase failure/reverse, and timing.
· Others: Leakage and outage protection, overload fusing protection, audio signal alarm, power leakage and overload protection.
Programmable controller
▸7-inch programmable touchscreen controller
▸Fix value mode or programs mode settings
▸Temperature setting realtime temperature profile
▸Test data download
Features
▸Working zone is made of SUS#304 brushed stainless steel
▸Uniform temperature distribution and stability
▸Original imported France "Tecumseh" refrigeration compressors
▸25mm diameter cable port locates at the right side
Benefits
·Easy installation
·Precise temperature control in small chamber
·Desktop type designed for limited space laboratory
·Over-temperature limiter
·Programmable LCD controller
·Record 365 days history data
·Temperature & humidity realtime and history curve display
·RS485 computer interface for data download
Application
The programmable benchtop temperature chamber is a compact and efficient solution for conducting thermal testing and conditioning on a small scale. These chambers are designed to fit on a laboratory bench, making them ideal for environments with limited space.
▸Material Testing: Evaluating the thermal properties and durability of materials under various temperature conditions.
▸Electronics Testing: Stress testing of electronic components and circuits to ensure reliability under different thermal conditions.
▸Biological Research: Studying the effects of temperature on biological samples, such as cell cultures or pharmaceuticals.
▸Industrial Quality Control: Ensuring products can withstand specified temperature ranges during transportation and use.
How to set fix value and programs?
▸Fix value setting: 85°C
▸Programs setting: Heat up to 85°C, constant 5 hours @85°C, cool down to 30°C, constant 2 hours@30°C, cool down to 0°C, constant 6 hours @0°C, cool down to -20°C, constant 2 hours@-20°C, then take out @23°C.
What are advantages of Climatest Symor® programmable benchtop temperature chamber?
▸Wide Temperature Range: Climatest Symor® chambers offer a broad temperature range, enabling testing at both extremely low and high temperatures.
▸Uniform Temperature Distribution: Climatest Symor® chambers are designed to ensure uniform temperature distribution throughout the chamber.
▸Advanced Programmability: The programmable controllers allow users to set complex temperature profiles, including ramps, soaks, and cycles.
▸User Friendly Interface:The chambers are equipped with intuitive control interfaces, making it easy for users to program and monitor temperature settings.
▸Cost-Effectiveness: A good balance of features and affordability, the advanced capabilities typically found in higher-end models, making them a cost-effective solution for customers.
Packing
1: Wrap thin film onto the temperature chamber benchtop for waterproof and dustproof use.
2: Bind bubble foam on the temperature test chamber tightly, and then cover the machine with a big plastic bag.
3: Put the temperature test chamber into a reinforced plywood case with a pallet at the bottom.
This package is firm enough to withstand bumpy sea and railway transportation, and the product can be delivered to customers smoothly.
Shipment
The programmable mini temperature chamber suits the following shipping solutions:
▸To Europe: By sea, China-EU railway, China-EU truck
▸To North America/South America: By sea, Matson
▸To Southeast Asia: By sea, by road
▸To New Zealand/Australia: By sea
▸To Africa: By sea
Climatest Symor® arranges booking service, and cooperate with customers under different incoterms, such as CIF/FOB//EXW/DAP; Climatest Symor® also provides door to door service (incoterm: DDP), that means we handle all export and import shipments and papers, customers just sign for receipt.
Commonly Asked Questions and Answers
Q: What is the cost of the benchtop temperature test chamber?
A: If you are interested in our chambers, and wanna get a quotation, kindly advise your shipping address first, we can quote you a door-to-door price, and kindly contact our sales staff for a formal quotation.
Q: How noisy is the chamber during operation?
A: 65dB.
Q: What are the power requirements for the chamber?
A: The standard power is 220V/230V, 50HZ, and if you have other requirements, pls check with our salesman.
Q: What is the typical lead time for delivery?
A: The production lead time is seven working days.
Q: Are there any reviews or testimonials from other users?
A: Yes, we have customers in Europe, the USA, and Southeast Asia with good feedback.
