Climatest Symor® benchtop thermal chamber is a mini type for the smaller specimens in a limited-space laboratory. A benchtop thermal chamber offers the ideal conditions to test the resistance of specimens against extreme temperatures and provides an optimal testing solution with a compact volume of 12L, 22L, and 36L. It Combines high durability with excellent working performance. A benchtop temperature chamber has become the best seller in laboratories and research institutes.
Model: TGDW-22
Capacity: 22L
Shelf: 1pc
Color: Off-white
Interior dimension: 320×250×250 mm
Exterior dimension: 520×560×730 mm
Description
Climatest Symor® is a benchtop thermal chamber manufacturer and supplier in China, this temperature test chamber is small enough to be placed on the benchtop, and it provides accurate, precise PID control of temperature levels, with easy installation and convenient operation, the users can perform temperature tests with a range of -40°C~+130°C.
Specification
| Model | TGDW-12 | TGDW-22 | TGDW-36 |
| Interior Dimension(W*D*H) | 310×230×200 mm | 320×250×250 mm | 400×300×300 mm |
| Exterior Dimension(W*D*H) | 500×540×650 mm | 520×560×660 mm | 640×730×970 mm |
| Temperature Range | Model A :-20°C~+130°C Model B: -40°C~+130°C | ||
| Temperature Fluctuation | ≤±0.5°C | ||
| Temperature Bias | ≤±1.0°C | ||
| Temperature Uniformity | ≤1.5°C | ||
| Heating Rate | +25℃～+130℃≤30 minutes(unload) | ||
| Cooling Rate | +25℃～-40℃≤45 minutes(unload) | ||
| Interior Material | SUS#304 brushed stainless steel | ||
| Exterior Material | Reinforced Steel plate with electrostatic spraying | ||
| Insulation | Superfine fiberglass wool/polyurethane foam | ||
| Controller | 7” Programmable touchscreen controller | ||
| Circulation System | Low-noise, high temperature resistant motors, long axis and stainless steel multi-leaf type centrifuge fan | ||
| Heating System | NiCr heater, independent system | ||
| Refrigeration System | France "TECUMSEH" Refrigeration Compressors, air cooling | ||
| Power Supply | AC110V/220V/AC230V·50HZ/60HZ | ||
Safety protection:
· Independent temperature limiter.
· Over-heat, over-current and over-pressure protection of compressor.
· Over-temperature protection, overheat of fan and motor, phase failure/reverse, and timing.
· Leakage and outage protection, overload fusing protection, audio signal alarm, power leakage, and overload protection.
Features
▸Compact Design:
. Small Footprint: Designed to fit on laboratory benches, desks, or workstations.
. Portable: Lightweight and easy to move within the facility.
▸Temperature Control:
. Wide Temperature Range: Capable of maintaining temperatures from -40°C to 150°C
. Precision: High accuracy in maintaining set temperature conditions.
▸User-Friendly Interface:
. Digital Displays: Easy-to-read displays for monitoring temperature and other parameters.
. Programmable Controls: Intuitive controls for setting and adjusting temperature cycles and profiles.
▸Rapid Temperature Cycling:
. Fast Response Time: Ability to quickly reach and maintain desired temperatures, facilitating rapid thermal cycling tests.
▸Safety Features:
. Alarms and Alerts: Built-in alarms to notify users of temperature deviations.
. Overheat Protection: Mechanisms to prevent overheating and ensure sample safety
Benefits
·Easy installation
·Precise temperature control in small chamber
·Desktop type designed for limited space laboratory
·Over-temperature limiter
·Programmable LCD controller
·Record 365 days history data
·Temperature & humidity realtime and history profile display
·RS485 computer interface for data download
Application of benchtop thermal chambers
▸Electronics Testing:
. Component Stress Testing: Evaluating the performance and durability of electronic components， such as semiconductors, circuit boards, and sensors under various temperature conditions.
. Thermal Cycling: Assessing the reliability and lifespan of electronic devices through repeated temperature changes.
▸Materials Testing:
. Thermal Expansion: Studying how materials expand and contract with temperature changes.
. Durability Testing: Evaluating the durability of materials under repeated thermal cycling
▸Automotive and Aerospace:
. Component Testing: Evaluating the performance of automotive and aerospace components under extreme temperature conditions.
. Quality Control: Ensuring components meet industry standards for temperature tolerance.
▸Academic and Research Laboratories:
. Experimental Research: Providing controlled temperature conditions for various research experiments in fields such as chemistry, biology, and physics.
. Educational Use: Allowing students to conduct hands-on experiments that require precise temperature control.
What can you benefit from Climatest Symor® benchtop thermal chambers?
Benchtop thermal chambers offer numerous benefits, making them an essential tool for various testing and research.
▸Cost-Effectiveness: Customers can get these mini temp chambers at competitive prices, and make big progress on their research. The test chamber is affordable, making advanced testing accessible to smaller labs and businesses, it also consumes less energy and requires less maintenance, leading to lower operational expenses.
▸Precision and Control: Provides precise control over a wide range of temperatures, this helps customers collect more accurate data, and increase efficiency of their experiments.
▸Reliable Performance: Stable and reproducible test conditions is essential for product testing, this helps reproduce experiments and validating results in scientific research.
▸Better Quality Control: Many customers require strict adherence to regulatory standards, this chamber ensures consistent quality control processes, and enhances their research capabilities.
Calibration
Each Climatest Symor® benchtop thermal chamber comes with a calibration certificate calibrated by SGS, an ISO17025 accredited laboratory. We strictly control the performance and quality of our desktop temperature test chambers. Our quality control tracks the entire process from production to commissioning. At the same time, we require the SGS laboratory to calibrate again before shipment to ensure that customers are satisfied with the machine and that it can be put into use immediately after receipt.
Fix value and program setting
▸Fix value setting: 85°C
▸Programs setting: Heat up to 85°C, constant 5 hours @85°C, cool down to 30°C, constant 2 hours@30°C, cool down to 0°C, constant 6 hours @0°C, cool down to -20°C, constant 2 hours@-20°C, then take out @23°C.
Packing
1. Wrap thin film onto the chamber for waterproof and dustproof purpose.
2. Bind bubble foam on temperature test chamber tightly, and then cover the machine with a big plastic bag.
3. Put it into a reinforced polywood case with pallet.
This package is firm enough to withstand bumpy sea and railway transportation, and ensure the product is delivered to customers smoothly.
Frequently Asked Questions and Answers
Q: What is the price of the benchtop thermal chamber?
A: Prices differ depending on the parameters, volumes, and shipping address, pls contact our sales staff for a formal quotation by emailing sales@climatechambers.com.
Q: What is the noise level during operation?
A: 65 dB.
Q: What is the warranty period, and what does it cover?
A: One year with lifetime free technical support, any issues within warranty period, we will provide service for free within 24 hours.
Q: What is the lead time for delivery?
A: 7 days for standard models, and pls check with us for customized models.
