Climatest Symor® benchtop temperature chamber price is competitive. The benchtop design is tailor-made for the smaller specimens in the limited-space laboratory. A benchtop temperature test chamber offers the ideal conditions to test the resistance of specimens against extreme temperatures and provides an optimal testing solution with a compact volume of 12L, 22L, and 36L. It combines the advantages of high durability with excellent working performance. This benchtop temperature test chamber has become the best seller in laboratories and research institutes.
Model: TGDW-36
Capacity: 36L
Shelf: 1pc
Color: Off-white
Interior dimension: 400×300×300 mm
Exterior dimension: 640×730×970 mm
Description
Customers can purchase good quality benchtop temperature chambers at factory price/affordable price from Climatest Symor®. The benchtop temperature chamber is small enough to be placed on the table and provides accurate, precise PID control of temperature levels with easy installation and convenient operation, the user can perform temperature tests with a range of -40°C~+130°C.
Specification
| Model | TGDW-12 | TGDW-22 | TGDW-36 |
| Interior Dimension(W*D*H) | 310×230×200 mm | 320×250×250 mm | 400×300×300 mm |
| Exterior Dimension(W*D*H) | 500×540×650 mm | 520×560×730 mm | 640×730×970 mm |
| Temperature Range | Model A :-20°C~+130°C Model B: -40°C~+130°C | ||
| Temperature Fluctuation | ≤±0.5°C | ||
| Temperature Bias | ≤±1.0°C | ||
| Temperature Uniformity | ≤1.5°C | ||
| Heating Rate | +25℃～+130℃≤30 minutes (unload) | ||
| Cooling Rate | +25℃～-40℃≤45 minutes (unload) | ||
| Interior Material | SUS#304 brushed stainless steel | ||
| Exterior Material | Reinforced Steel plate with electrostatic spraying | ||
| Insulation | Superfine fiberglass wool/polyurethane foam | ||
| Controller | 7” programmable touchscreen controller | ||
| Circulation System | Low-noise, high temperature resistant motors, long axis and stainless steel multi-leaf type centrifuge fan | ||
| Heating System | NiCr heater, independent system | ||
| Refrigeration System | France "TECUMSEH" Refrigeration Compressors, air cooling | ||
| Power Supply | AC110V/220V/AC230V·50HZ/60HZ | ||
Safety protection:
· Independent temperature limiter
· Over-heat, over-current and over-pressure protection of compressor.
· Over-temperature protection, overheat of fan and motor, phase failure/reverse, and timing.
· Leakage and outage protection, overload fusing protection, audio signal alarm, power leakage, and overload protection
Programmable controller
▸7-inch programmable touchscreen controller
▸Fixed value mode or program mode settings
▸Real-time temperature profile display
▸Test data can be downloaded through the RS485 interface
Features
▸Compact Design: Designed to fit on a benchtop, making it ideal for laboratories and facilities with limited space.
▸Temperature Range: Typically can simulate temperatures from -40°C to 150°C (-40°F to 302°F)
▸Precision and Control: Providing precise control over temperature ranges, and programmable settings for easy and accurate adjustments.
▸User-Friendly Design: Simple controls and displays make it easy to set up and operate, even for users with limited technical expertise.
▸Safety Features: Includes over-temperature protection, alarms, and other safety mechanisms to ensure safe operation.
Benefits
·Easy installation
·Precise temperature control in small chamber
·Desktop type designed for limited space laboratory
·Over-temperature protection
·Programmable LCD controller
·Record 365 days history data
·Temperature & humidity realtime and history profile display
·RS485 computer interface for data download
Application
As a reliable test equipment for quality control engineering, the benchtop temperature chamber simulates high temperature, low temperature, temperature alternating environments to test various products and materials’ performance to withstand continuous harsh climate conditions, The benchtop temperature chamber is applicable to industries:
▸Electronic& Semiconductor Industry:
The benchtop temperature chamber can evaluate damages to insulation materials, sticking of contacts, performance changes, and adverse reactions of electronic components. Moreover, if semiconductor devices, such as integrated circuits, liquid crystals, and silicon wafers, are stored in a high-humidity environment for a long time, the pads and chip pin surfaces are easy to be oxidized and cause failures such as poor contact.
▸Plastics Industry:
Plastic enclosures and containers are everywhere in our lives, including household appliances, instrumentation, construction equipment, the automobile industry, daily hardware, and more. Plastic products have increased rapidly in recent years, and to improve quality and competitiveness, manufacturers now pay more attention to the reliability testing of their plastic products.
Benchtop temperature chamber simulates harsh environments, like high and low temperature to help manufacturers detect defects in their plastic enclosure in a short time, benchtop temperature chamber provides them valuable data collection during the R&D stage, and greatly improve the production efficiency and save the cost.
▸Automobile Industry:
The benchtop temperature chamber is one of the most crucial environment testing equipment. Products are like going through "torture" through environmental testing. Auto parts are tested, problems are discovered, and the initial product design is iteratively modified to improve the product to best suit the working environment throughout its life cycle.
Benchtop temperature chambers work in communications, pharmaceutical, military, and packaging industries. By simulating natural and accelerated environments for testing needs, the desktop constant temperature chamber provides reliable environmental testing, and it can efficiently detect product performance changes in different environments and plays a vital role in the product development stage.
How to set fix value and programs?
▸Fix value setting: 85°C
▸Programs setting: Heat up to 85°C, constant 5 hours @85°C, cool down to 30°C, constant 2 hours@30°C, cool down to 0°C, constant 6 hours @0°C, cool down to -20°C, constant 2 hours@-20°C, then take out @23°C.
What are the advantages of Climatest Symor® benchtop temperature chamber?
▸Space Efficiency: Takes up less room than larger chambers, freeing up valuable workspace.
▸Portability: Lightweight allows for easy relocation to different sites.
▸Cost-Effectiveness: Consumes less energy and requires less maintenance, leading to lower operational expenses.
▸Precision and Control: Provides precise control over temperature ranges, ensuring reliable and consistent testing conditions.
▸User-Friendly Design: Simple controls and displays make it easy to set up and operate.
Calibration
Every Climatest Symor® benchtop temperature chamber is equipped with a calibration certificate, calibrated by SGS, the ISO17025 certified lab. We strictly controls the performance and quality of the benchtop temperature test chambers. Our QC follows up the whole process from production to commissioning. At the same time, we invite SGS lab to calibrate again before shipping, this ensures our customers are satisfied after receiving the machine and can be put into use immediately.
The temperature uniformity is controlled within 1.5°C, bias is controlled within ±1.0°C, and the machine performs very well with low maintenance and operation costs.
Packing
1. Wrap thin film onto the test chamber for waterproof and dustproof use.
2. Bind bubble foam on the temperature test chamber tightly, and then cover the machine with a big plastic bag.
3. Put the temperature test chamber into a reinforced plywood case with a pallet at the bottom.
This package is firm enough to withstand bumpy sea and railway transportation, and the product can be delivered to customers smoothly.
Shipping
The benchtop temperature chamber suits the following shipping solutions:
▸To Europe: By sea, China-EU railway, China-EU truck
▸To North America/South America: By sea, Matson
▸To Southeast Asia: By sea, by road
▸To New Zealand/Australia: By sea
▸To Africa: By sea
Climatest Symor® arranges booking, and cooperates with customers under different incoterms, such as CIF/FOB/EXW/DAP; Climatest Symor® also provides door-to-door service (incoterm: DDP), which means we handle all export and import procedures, customers just sign for receipt.
Frequently Asked Questions and Answers
Q: How much does the benchtop temperature chamber cost, and are there additional costs?
A: Prices differ depending on the parameters, volumes, and shipping address, there are no additional costs, pls contact our sales staff for a formal quotation by emailing sales@climatechambers.com.
Q: What is the warranty period, and what does it cover?
A: One year with lifetime free technical support, any issues happen within this period, we will settle it for free.
Q: What type of control system does the chamber use?
A: A user-friendly control system with an intuitive interface can enhance usability. Features to look for include programmable settings, touchscreens, and data logging.
Q: What is the lead time for delivery?
A: 7 days for standard models, and pls check with us for customized models.
