Climatest Symor® is a desktop thermal chamber manufacturer and supplier in China, the desktop thermal chamber is small enough to be placed on the benchtop in laboratories and research institutes, it provides precise temperature control with an intelligent PID function. The desktop thermal chamber is an easy-to-operate machine, the user can perform various temperature tests with a range of -40°C~+130°C.
Model: TGDW-36
Capacity: 36L
Shelf: 1pc
Color: Off-white
Interior dimension: 400×300×300 mm
Exterior dimension: 640×730×970 mm
Description
Climatest Symor® desktop thermal chamber is a compact, portable device specifically designed to simulate temperatures from -40°C to 150°C for testing and research purposes. These chambers are small enough to fit on a desktop or benchtop, making them ideal for environments with limited space.
Specification
| Model | TGDW-12 | TGDW-22 | TGDW-36 |
| Interior Dimension(W*D*H) | 310×230×200 mm | 320×250×250 mm | 400×300×300 mm |
| Exterior Dimension(W*D*H) | 500×540×650 mm | 700×440×700 mm | 640×730×970 mm |
| Temperature Range | Model A :-20°C~+130°C Model B: -40°C~+130°C | ||
| Temperature Fluctuation | ≤±0.5°C | ||
| Temperature Bias | ≤±1.0°C | ||
| Temperature Uniformity | ≤1.5°C | ||
| Heating Rate | +25℃～+130℃≤30 minutes (unload) | ||
| Cooling Rate | +25℃～-40℃≤45 minutes (unload) | ||
| Interior Material | SUS#304 brushed stainless steel | ||
| Exterior Material | Reinforced Steel plate with electrostatic spraying | ||
| Insulation | Superfine fiberglass wool/polyurethane foam | ||
| Controller | 7” Programmable touchscreen controller | ||
| Circulation System | Low-noise, high-temperature resistant motors, long axis and stainless steel multi-leaf type centrifuge fan | ||
| Heating System | NiCr heater, independent system | ||
| Refrigeration System | France "TECUMSEH" Refrigeration Compressors, air cooling | ||
| Power Supply | AC110V/220V/AC230V·50HZ/60HZ | ||
Safety protection:
· Independent temperature limiter
· Over-heat, over-current and over-pressure protection of compressor.
· Over-temperature protection, overheat of fan and motor, phase failure/reverse, and timing.
· Leakage and outage protection, overload fusing protection, audio signal alarm, power leakage, and overload protection.
Key Features
▸Compact Size
. Small footprint designed to fit on desktops or benchtops
. Lightweight and easy to move if necessary
▸Precise Temperature Control
. Capable of accurately controlling temperatures
. Touch screen interfaces with programmable settings
▸User-Friendly
. Easy-to-use controls and displays for setting and monitoring temperatures
. Touchscreens for ease of use
▸Rapid Temperature Cycling
. Quickly ramp up or down to desired temperatures, facilitating rapid thermal cycling tests
. Stable and consistent temperature
How to set fix value and programs?
▸Fix value setting: 85°C
▸Programs setting: Heat up to 85°C, constant 5 hours @85°C, cool down to 30°C, constant 2 hours@30°C, cool down to 0°C, constant 6 hours @0°C, cool down to -20°C, constant 2 hours@-20°C, then take out @23°C.
Application
▸Electronics Testing:
. Component Testing: Stress testing of electronic components, such as semiconductors, circuit boards, and sensors.
. Device Reliability: Assessing the reliability and performance of electronic devices when exposed to temperature extremes.
▸Materials Testing:
. Thermal Expansion: Studying the thermal expansion and contraction properties of materials.
. Durability Testing: Evaluating the durability of materials and products under repeated temperature cycling.
▸Automotive Industry:
. Component Testing: Testing automotive components such as sensors, batteries, and electronics.
. Quality Control: Ensuring automotive parts meet industry standards for temperature tolerance.
▸Academic and Educational Use:
. Laboratory Experiments: Providing hands-on experience for students in controlling and monitoring temperatures.
. Research Projects: Supporting academic research projects that require precise temperature control.
Do you have the problem of limited space in your laboratory?
Climatest Symor® deskop thermal chamber can conduct high-low temperature tests for small samples , a temperature range of -40℃ to +150℃ makes it possible to test samples’ resistance against extreme temperature changes. Deskop thermal chamber provides users with a compact design tailor-made for small products, the operation is environmental and quiet, it is the best seller in universities and research institutes.
Why choose Climatest Symor® deskop thermal chamber?
Choosing a Climatest Symor® deskop thermal chamber means opting for precision, reliability, and flexibility, here are our advantages:
▸High Precision and Accuracy
. Equipped with advanced control systems that ensure precise temperatures, the temperature uniformity is ≤1.5°C, and temperature bias is ≤±1.0°C
Climatest Symor® strictly controls the performance and quality of the benchtop temperature chambers. Our QC follows up the whole process from production to commissioning. At the same time, we invite SGS lab to calibrate again before shipping, this ensures our customers are satisfied after receiving the machine and can be put into use immediately. Every benchtop temperature chamber is calibrated by SGS, the ISO17025 certified laboratory.
▸Cost-Effective Solution
. Affordable Pricing: Climatest Symor® offers a cost-effective benchtop-type temperature test chambers, making advanced testing accessible to more users.
. Low Maintenance: Designed for easy maintenance, these chambers reduce research and maintenance costs.
▸Energy Efficiency
. Low Power Consumption: Energy-efficient, operational costs are saved while maintaining high performance.
. Environmentally Friendly: CFC free, contributing to reduced environmental impact.
Packing
1. Wrap thin film onto the test chamber for waterproof and dustproof use.
2. Bind bubble foam on mini temperature test chamber, and then cover the machine with a plastic bag.
3. Put temperature test chamber into a reinforced polywood case with pallet.
4. A thin film is wrapped again on the package for waterproof use.
Climatest Symor® provides booking service, we work with customers on different incoterms, such as CIF/FOB/EXW/DAP; and we also provides door-to-door service (incoterm: DDP), customers just sign for receipt.
▸To Europe: By sea, China-EU railway, China-EU truck
▸To North America/South America: By sea, Matson
▸To Southeast Asia: By sea, by road
▸To New Zealand/Australia: By sea
▸To Africa: By sea
Frequently Asked Questions and Answers
Q: How to maintain the desktop thermal chamber?
A: The test chamber is low maintenance, regular maintenance includes cleaning the work area after each test and turning off the power if left idle for an extended period of time, see our user manual for details.
Q: How much does a desktop thermal chamber cost?
A: Costs vary based on parameters, quantity and shipping address, please contact our sales staff via email at sales@climatechambers.com for a formal quote.
Q: Can I customize a desktop thermal chamber?
A: Yes, we can customize according to your technical parameters, the delivery time is 30 days, please contact our sales via email sales@climatechambers.com.
Q: Is this benchtop temp chamber noisy when running?
A: The noise is 65 decibels.
