Climatest Symor® is a manufacturer of high temperature industrial ovens, which are designed to accommodate a variety of load sizes and yields. Our ovens are known for accurate temperature control, higher yields, and consistent, reproducible results, providing constant uniform temperature, contributed by their robust construction quality and design.
Model: TBPG-9200A
Capacity: 90L
Interior Dimension: 600*600*600 mm
Exterior dimension: 950*885*840 mm
Description
High temperature industrial ovens adopt vertical or horizontal air circulation at competitive prices, it is recommended for a variety of manufacturing and laboratory applications, including curing, hardening, annealing, and material testing. The ovens feature user-friendly digital display interfaces with programmable temperature cycles settings. This allows users to set the customized heating cycles according to their specific requirements.
Specification
| Model | TBPW-9030A | TBPW-9050A | TBPW-9100A | TBPW-9200A |
|
Interior Dimension (W*D*H) mm |
320*320*300 | 350*350*400 | 450*450*450 | 600*600*600 |
|
Exterior Dimension (W*D*H) mm |
665*600*555 | 695*635*635 | 795*730*690 | 950*885*840 |
| Temperature Range | 100°C ~ 500°C | |||
| Temperature Fluctuation | ± 1.0°C | |||
| Temperature Resolution | 0.1°C | |||
| Temperature Uniformity | ± 1.5% | |||
| Shelves | 2 PCS | |||
| Timing | 0~ 9999 min | |||
| Power Supply | AC380V 400V 415V 480V 50HZ/60HZ | |||
| Ambient Temperature | +5°C~ 40°C | |||
Feature
►High temperature up to 400°C, 500°C, 600°C
►PID microprocessor based temperature controller
►Over temperature protection monitor
►Optimized insulation minimizes heat loss
►Sheathed heating element
►Emergency mushroom button
Option
►Programmable temperature controller
►Nitrogen purging system
►Over temperature buzzer alarm
►Three-color flashing light alarm
►Communication with RS485 interface
High temperature industrial oven
Climatest Symor® is a high temperature industrial oven manufacturer in China, we are dedicated to designing, manufacturing and serving industrial ovens at competitive prices, the ovens are available in 4 different standard sizes, and customizable for your products application, there are variety of customized options for your selection.
High temperature industrial ovens offer fast responsive 500°C continuously operating chamber, the exterior is made of galvanized steel finished in an easy-to-clean powder spraying, each with a single hinged door and a blast proof handle. The walls and doors are well insulated to reduce heat loss. The interior chamber/heating element/racks are made of stainless steel 304, providing adjustable air inlet and outlet circulation ports.
Our standard controller is a digital display, the programmable controller is optional, and it has auto-tuning and settable ramp rate functions, this feature provides precise and stable control from the power-on moment.
For operation on 380VAC, 50/60HZ, 400V or 415V, 480V are also available.
Benefits
Quality Assurance: High temperature industrial ovens ensure the quality and reliability of manufactured products, the ovens enable precise control over critical thermal processes. This quality assurance is essential in industries where material properties and product performance are paramount, such as aerospace, automotive, and electronics.
Improved Efficiency: High temperature industrial ovens accelerate processing times for heat treatment, drying, curing, and other thermal processes. Their ability to reach and maintain high temperatures reduces processing time, thereby improving production efficiency and research workflows.
Cost Savings: By optimizing processing parameters and reducing cycle times, high temperature industrial ovens contribute to cost savings in production processes. Improved efficiency, enhanced material properties, and reduced energy consumption translate into lower manufacturing costs and higher profitability.
Application
Climatest Symor® makes efforts to become an outstanding manufacturer of high temperature industrial ovens in China, there are a variety of applications in the following industries.
Drying and Curing
Industries involved in coatings, paints, adhesives, and other surface treatments require high temperature industrial ovens for the drying and curing processes. These ovens accelerate evaporation of solvents, facilitate cross-linking reactions, and ensure proper adhesion and coating.
Chemical Synthesis
In chemical industries and research laboratories, high temperature industrial ovens are used to synthesize chemical compounds, catalyst activation, and thermal decomposition reactions. These ovens provide the necessary conditions to drive the chemical reactions at high temperatures.
Laboratory Research
High temperature industrial ovens are indispensable instruments in scientific research laboratories. They are used in various experiments and analysis required to control high temperatures, such as studying material properties, conducting thermal decomposition studies, and synthesizing new materials.
500°C Industrial high-temperature industrial ovens are widely used in various industries, including metallurgy, ceramics, polymers, chemicals, electronics, and research, in which precise temperature control is essential for material processing, synthesis, and experimentation.
