An epoxy curing oven is designed for curing epoxy resins. Epoxy resins are widely used in various industries for bonding, sealing, coating, and encapsulating materials due to their excellent adhesive properties, chemical resistance, and mechanical strength. Epoxy curing oven provides controlled temperature environments to accelerate the curing process of epoxy resins, ensuring proper cross-linking and hardening of the resin.
Model: TBPG-9050A
Capacity: 50L
Interior Dimension: 350*350*400 mm
Exterior dimension: 695*635*635 mm
Description
As a manufacturer of epoxy curing ovens, Climatest Symor® is committed to producing high-performance and reliable temperature controlled equipment, our ovens utilize hot air convection systems to ensure uniform heat distribution inside the chamber, and feature digital controls allowing users to create different temperature levels, there are adjustable shelves or racks where products can be placed.
Specification
| Model | TBPB-9030A | TBPB-9050A | TBPB-9100A | TBPB-9200A | |
|
Interior Dimension (W*D*H) mm |
320*320*300 | 350*350*400 | 450*450*450 | 600*600*600 | |
|
Exterior Dimension (W*D*H) mm |
665*600*555 | 695*635*635 | 795*730*690 | 950*885*840 | |
| Temperature Range | 50°C ~ 200°C | ||||
| Temperature Fluctuation | ± 1.0°C | ||||
| Temperature Resolution | 0.1°C | ||||
| Temperature Uniformity | ± 1.5% | ||||
| Shelves | 2 PCS | ||||
| Timing | 0~ 9999 min | ||||
| Power Supply | AC220V 230V 240V 50HZ/60HZ | AC380V 400V 415V 480V 50HZ/60HZ | |||
| Ambient Temperature | +5°C~ 40°C | ||||
Epoxy curing oven
Curing applications use heat to produce a chemical reaction to cure the surface or adhesive on the product, or to cure the plastic or epoxy resin. The result is a harder, and more stable material or coating against temperature, humidity, or corrosion.
Climatest Symor® is an epoxy curing oven manufacturer, we are good at temperature and humidity control technology, our curing ovens are used for curing epoxy resin, powder coatings, adhesive coatings, thermoplastics, rubber, coatings, carbon fibers, polymers, plastic composites.
Benefits of epoxy curing oven
Increase productivity: Drying & curing process can accelerate the production process, reduce production time, and save costs.
Accelerated curing process: Epoxy curing ovens accelerate the curing process of epoxy resins. By maintaining consistent temperatures and optimal curing conditions, these ovens ensure rapid cross-linking and hardening of the epoxy resin, reducing curing times compared to ambient curing methods.
Improved quality and performance: Proper curing in epoxy curing ovens results in improved quality and performance of epoxy-based materials and products. The controlled curing process helps achieve optimal mechanical properties, adhesion strength, chemical resistance, and dimensional stability in the final products, ensuring superior durability and reliability.
Reduced Waste and Rework: By ensuring proper curing of epoxy resins, epoxy curing ovens help reduce the risk of defects, rework, and material waste in manufacturing processes.
Application
Climatest Symor® is committed to becoming an excellent manufacturer of epoxy curing ovens in China, our ovens find application in various industries for a wide range of processes. Here are some common applications:
Composite Manufacturing
Epoxy curing ovens are widely used in the manufacturing of composite materials, such as carbon fiber reinforced polymers (CFRP), fiberglass reinforced polymers (FRP), and other composite laminates. These ovens help cure epoxy resin matrices used to bond and reinforce composite layers, resulting in strong and lightweight composite structures.
Electronics Assembly
In the electronics industry, epoxy curing ovens are utilized for curing epoxy adhesives and encapsulants, which are used in the assembly and packaging of electronic components and circuit boards. These ovens ensure proper bonding, insulation, and protection of electronic devices against environmental factors, such as moisture, dust, and vibration.
Coating and Sealing
Epoxy curing ovens are used for curing epoxy coatings and sealants applied to various substrates such as metal, concrete, wood, and ceramics. These coatings provide corrosion protection, chemical resistance, and surface durability in architectural, marine, industrial, and decorative applications.
